Description
Designed to perform in heavy-equipment shops, fleet maintenance shops, municipal garages and higher-volume in-plant applications with longer plumbing runs and larger fluid usage.
Typical applications include heavy-duty dealerships, fleet service facilities, in-plant, lube trucks, and mining.
Specifications
| Dispense Type | Manual |
|---|---|
| Extension Type | Rigid |
| Fluid Inlet Thread Gender | Female |
| Fluid Outlet Thread Gender | Female |
| Includes | Extension, Hydraulic Coupler |
| Inlet Size (cm) | 0.635 |
| Maximum Operating Temperature (°C) | 60 |
| Meter Accuracy (%) | ±0.3 |
| Inlet Size (mm) | 6.35 |
| Inlet Size (in) | 1/4 |
| Maximum Working Pressure (psi) | 5000 |
| Maximum Working Pressure (MPa) | 34.5 |
| Maximum Working Pressure (kPa) | 34500 |
| Maximum Working Pressure (bar) | 345 |
| Outlet Size (in) | 1/8 |
| Outlet Size (mm) | 3.175 |
| Maximum Operating Temperature (°F) | 140 |
| Meter Technology | Oval Gears |
| Metering Gun Weight (kg) | 1 |
| Metering Gun Weight (lb) | 2.2 |
| Overall Length (in) | 3.2 |
| Overall Length (mm) | 81.28 |
| Overall Width (cm) | 4.572 |
| Overall Width (in) | 1.8 |
| Repeatability | ±0.1 |
| Valve Type | Metered |
| Outlet Size (cm) | 0.3175 |
| Approvals | CE |
| Overall Height (cm) | 22.35 |
| Overall Height (in) | 8.8 |
| Overall Height (mm) | 223.5 |
| Overall Length (cm) | 8.13 |
| Trigger Lock | Non-Locking |
| Warranty | 2 |
| Overall Width (mm) | 45.72 |
