Tracks totals in two modes – reset for periodic history and
Typical applications include automotive and heavy-duty dealerships, service and fast lube centers, fleet service facilities and in-plant.
Description
- Durable design for rugged, indoor use
- Easy to use – dispenses pints, quarts, liters or gallons
- 0.5 gpm to 15 gpm (1.9 lpm to 57 lpm) flow rate
- 1500 psi (103 bar) maximum pressure, 1/2 in NPT inlet
Specifications
| Battery Chemistry | Alkaline |
|---|---|
| Battery Size | AA |
| For Use With | Diesel Exhaust Fluid |
| Inlet Size (cm) | 1.27 |
| Inlet Size (in) | 0.5 |
| Inlet Size (mm) | 12.7 |
| Maximum Flow Rate (L/min) | 57 |
| Maximum Operating Temperature (°C) | 50 |
| Maximum Operating Temperature (°F) | 122 |
| Maximum Working Pressure (bar) | 105 |
| Maximum Working Pressure (kPa) | 10500 |
| Maximum Working Pressure (psi) | 1500 |
| Meter Accuracy (%) | ±0.5 |
| Meter Repeatability (%) | ±0.15 |
| Minimum Operating Temperature (°C) | -20 |
| Minimum Operating Temperature (°F) | -4 |
| Weight (kg) | 0.82 |
| Maximum Working Pressure (MPa) | 10.5 |
| pulse_output | No |
