Description
The GrandPrix GP-9LC is a rugged 9,000-lb. capacity two-post lift built for low-ceiling garages and tough shop conditions. Its floorplate design removes overhead obstructions, while symmetric and asymmetric arm configurations provide flexible vehicle access. A proven chain-over system with industrial-grade leaf chain and heavy-duty rollers delivers smooth, reliable lifting backed by serious durability. With automatic safety locks, oversized base plates, and rock-solid construction, the GP-9LC is built to work as hard as you do.
- 9,000-lb. lifting capacity
- Symmetric and asymmetric arm design for enhanced versatility
- Triple-telescoping front arms & dual-stage extended rear arms
- Heavy-duty, high-strength leaf chain engineered for reliable lifting power and durability
- Heavy-duty 6" x 6" tubular steel carriage for maximum strength
- Electric-hydraulic power system for effortless operation
- Oversized 20.5" x 15.5" base plate for increased stability
- Self-lubricating UHMW polyethylene guide blocks for long-lasting durability
- Safety locks in each column spaced every 3 inches
- Automatic arm restraints for enhanced safety
- Heavy-duty 1/2" aircraft-quality equalizer cables
- Oversized cable sheaves to reduce cable fatigue
- Double-telescoping screw pads feature tear-resistant polyurethane for long-lasting durability
- Full size rubber carriage guard reduces door dings
- 4-piece 63mm stackable adapter set included
- 10-piece concrete wedge anchors included
- 36-month limited warranty
Specifications
Lifting Capacity
9,000 lbs. (4,082 kg)
Max. Capacity / Front Axle
4,500 lbs. (2,045 kg)
Max. Capacity / Rear Axle
4,500 lbs. (2,045 kg)
A - Height Overall
109.5" (2,779 mm)
B - Width Overall (at Baseplate)
137.25" (3,486 mm)
C - Width Outside of Columns
127.5" (3,238 mm)
D - Floor To Driveover Height
1.25" (30 mm)
E - Width Inside Columns
113.25" (2,880 mm)
F - Front Arm Reach (Min.)
22.5" (571 mm)
F - Front Arm Reach (Max.)
43.25" (1,099 mm)
G - Rear Arm Reach (Min.)
33.25" (845 mm)
G - Rear Arm Reach (Max.)
53.50" (1,360 mm)
H - Min. Pad Height
4" (100 mm)
I - Rise
70" (1,780 mm)
J - Max. Lift Height (Pad + 63mm Adapt.)
76.5" - 78.5" (1,943 - 1,994 mm)
K - Drive-Thru Clearance
103" (2,618 mm)
Screw Pad Adjustment
2" (51 mm)
Motor
220 VAC / 60Hz / 1 Ph
Time of Full Rise
65 seconds
Max. Load Per Arm
2,250 lbs. (1,023 kg)
Shipping Weight
1,385 lbs. (630 kg)
